Suzhou Jinhong 2set1200 High Purity Hydrogen Fuel Cell Plant

Technology Application:

Under certain conditions of temperature, pressure and catalyst, the raw material is mixed with water steam for reforming and shift reaction (SMR) to generate a reforming gas containing H2, CO, CO2, N2 and CH4. After pressure swing adsorption(PSA) separation and purification, high purity hydrogen product is prepared.Hydrogen generation: In the absence of suitable hydrogen source, hydrogen is produced by chemical reaction with methanol, natural gas, biogas, coal and other chemical raw materials.

Key figures

Produces hydrogen of up to 99.999% purity

Capacity 200 to 1000 Nm3/h standardized equipment

Designed for unmanned, outdoor use

Units are compact and skid-mounted

Features and advantages:

Mature process technology and safe and reliable operation.

Short cycle of project construction and investment recovery rate to achieve strong market competitive.

Multistage margin recovery and the PSA desorption gas burn-back enabling energy saving and environmentally friendly.

Special adsorbent, low operating cost, high purity and high yield.

Special programmable control valve with high level ofautomatic.

Process Schematic
